Station Information



Coming in 2018 - Momobeam Antennas



Tower #1 60 foot Rohn 25G



  • Force 12 C31XR yagi
  • 6 Meter yagi



Tower #2 90 foot Rohn 25G



  • Force 12 240N 40 Meter yagi (two 56' elements on 23 foot boom)
  • Force 12 C3 yagi
  • Force 12 C19XR yagi - Fixed towards USA
  • 80 meter sloping dipole array - Switchable 4 directions
  • 160 meter Inverted L with 4 elevated radials



Cell Tower



  • 160 meter Inverted V



Receive Antennas



  • EU receive tribander - In farmer's field
  • EU Beverage - Not installed permanently. This needs to installed and hooked to switchbox at tower base
  • USA receive tribander - Not installed permanently
  • USA beverage - Not installed permanently. Need to hook to hardline cable that runs to road behind the house.



Station Documentation

Triplexer and 3 x 11 Antenna Switch - How to Guide

4x8 Receive Antenna Switch - How to Guide

160/80 Meter Antenna Switch - How to Guide

Dunestar 600 Band Pass Filters

Dunestar 800 Band Pass Filter Selector Box

Yaesu FT1000 MKV Manual

Ameriton AL1200 Manual

Alpha 91B Manual

Daiwa CN801 Watt Meter Manual

Elecraft K3 Manual

Force 12 C3 Manual

Shared Apex Loop Array

Momobeam
